New Three-Part ISO Document on Bevel Gears

The AGMA Technical Division informs of the publication of the following new documents by ISO Central:

−     ISO 10300-1:2023, Calculation of load capacity of bevel gears — Part 1: Introduction and general influence factors

−     ISO 10300-2:2023, Calculation of load capacity of bevel gears — Part 2: Calculation of surface durability (macropitting)

−     ISO 10300-3:2023, Calculation of load capacity of bevel gears — Part 3: Calculation of tooth root strength

[NOTE: As a reminder—because these are ISO documents AGMA has not adopted (but ISO lets AGMA sell), members will not be allowed to download these documents for free and there is no member discount. Descriptions are below.]

When ISO 10300:2001 (all parts) became due for its first revision, the opportunity was taken to include hypoid gears, since previously the series only allowed for calculating the load capacity of bevel gears without offset axes. The former structure is retained, i.e. three parts of the ISO 10300 series, together with ISO 6336-5, and it is intended to establish general principles and procedures for rating of bevel gears. Moreover, ISO 10300 (all parts) is designed to facilitate the application of future knowledge and developments, as well as the exchange of information gained from experience.

Pages: 64

Price: $225.00

SCOPE

This document specifies the methods of calculation of the load capacity of bevel gears, the formulae and symbols used for calculation, and the general factors influencing load conditions.

The formulae in this document are intended to establish uniformly acceptable methods for calculating the load-carrying capacity of straight, helical (skew), spiral bevel, Zerol and hypoid gears. They are applicable equally to tapered depth and uniform depth teeth. Hereinafter, the term “bevel gear” refers to all of the gear types; if not, the specific forms are identified.

The formulae in this document take into account the known major factors influencing load-carrying capacity. The rating formulae are only applicable to types of gear tooth deterioration, that are specifically addressed in the individual parts of the ISO 10300 series. Rating systems for a particular type of bevel gears can be established by selecting proper values for the factors used in the general formulae.

NOTE: This document is not applicable to bevel gears which have an inadequate contact pattern under load (see Annex D).

The rating system of this document is based on virtual cylindrical gears and restricted to bevel gears whose virtual cylindrical gears have transverse contact ratios of ε_vα

The user is cautioned that when the formulae are used for large average mean spiral angles (β_m1 + β_m2)/2 > 45°, for effective pressure angles α_e > 30° and/or for large facewidths b > 13 m_mn, the calculated results of this document should be confirmed by experience.

Pages: 42

Price: $155.00

SCOPE

This document specifies the basic formulae for use in the determination of the surface load capacity of straight and helical (skew), Zerol and spiral bevel gears including hypoid gears, and comprises all the influences on surface durability for which quantitative assessments can be made. This document is applicable to oil lubricated bevel gears, as long as sufficient lubricant is present in the mesh at all times.

The formulae in this document are based on virtual cylindrical gears and restricted to bevel gears whose virtual cylindrical gears have transverse contact ratios of ε_vα

The formulae in this document are not directly applicable to the assessment of other types of gear tooth surface damage, such as plastic yielding, scratching, scuffing or any other type not specified.

NOTE: This document is not applicable to bevel gears which have an inadequate contact pattern under load.

The user is cautioned that when the formulae are used for large average mean spiral angles (β_m1 + β_m2)/2 > 45°, for effective pressure angles α_e > 30° and/or for large facewidths b > 13 mmn, the calculated results of this document should be confirmed by experience.

Pages: 50

Price: $190.00

SCOPE

This document specifies the fundamental formulae for use in the tooth root stress calculation of straight and helical (skew), Zerol and spiral bevel gears including hypoid gears, with a minimum rim thickness under the root of 3.5 m_mn. All load influences on tooth root stress are included, insofar as they are the result of load transmitted by the gearing and able to be evaluated quantitatively. Stresses, such as those caused by the shrink fitting of gear rims, which are superposed on stresses due to tooth loading, are intended to be considered in the calculation of the tooth root stress, σ_F, or the permissible tooth root stress σ_FP. This document is not applicable in the assessment of tooth flank fracture.

The formulae in this document are based on virtual cylindrical gears and restricted to bevel gears whose virtual cylindrical gears have transverse contact ratios of ε_vα

This document does not apply to stress levels above those permitted for 10³ cycles, as stresses in that range can exceed the elastic limit of the gear tooth.

NOTE: This document is not applicable to bevel gears which have an inadequate contact pattern under load.

The user is cautioned that when the formulae are used for large average mean spiral angles (β_m1 + β_m2)/2 > 45°, for effective pressure angles α_e > 30° and/or for large facewidths b > 13 mmn, the calculated results of this document should be confirmed by experience.
